MY07C Automatic Woodworking Edge Banding bander Machinery for 3mm edge banding wood

Contact

Product Details

The high-speed automatic edge banding machine has the function of automatic end cutting, with its own vacuum device, clean and tidy. One-piece pressure beam, double rows of pressure wheels, silicone material conveyor belt, the sheet conveying is stable and not easy to scratch. It can seal multiple plates continuously, with convenient operation and high efficiency.



Product Parameters

Model

WF802

Function

automatic plate feeding, end cutting, upper and lower polishing, automatic head and tail trimming, comes with dust collector

Edge type

straight line

Rated voltage

220v

Strip thickness

0.5-2.5mm

Sheet thickness

10-50mm

Trimming power

800w*2

Polishing power

180w*2

Suction power

1200w

Rated power

4kw

Rated air pressure

0.4-0.6mpa

Feed plate

0-10m/min

Conveyer belt

0-10m/min

Glue capacity

4000ml

Heating power

1000w (5-10min)

Overall size

130*65*75cm

Machine weight

150kg
