Woodworking automatic kdt edge banding machine

Contact

Product Details

GLX506 automatic edge banding machine function

gluing and pressing-end cutting-rough trimming-fine trimming-scraping- buffing

Features
1.Through special structure, the edge-sealing sheet and the edge-sealing material are evenly coated and pressed, so that the edge-sealing strip is more firmly attached.
2.Through the precision linear guide motion, the rapid cutting structure of the high-frequency high-speed motor is automatically tracked by the master to ensure that the cut surface is smooth and smooth.
3.Rough trimming and fine trimming,ensure that the upper and lower plates are smoother and more tidy when trimming.
4.Used to eliminate the ripples caused by the cutting process of trimming non-linear motion.
5.Clean the finished plate with a cotton polishing wheel and smooth the edge of the edge by polish

model no GLX506
name automatic edge banding machine
motor power 9.2kw
feeding speed 12-20m/min
working thickness 10-60mm
edge band thickness                             0.4-3mm
working air pressure 0.8mpa
working width ≥40mm
weight 1900kg
overall dimensions 4150mm*1100mm*1600mm
