6090 best cnc router machine for beginners
They can be used for solid wood, metal, stone, PVC, rubber and plastic, polyurethane，etc. Mainly used in solid wood furniture, sanitary ware, luggage, machinery manufacturing, etc.
Technical parameters
|
Model |
6090 |
|
X,Y working area |
600×900mm |
|
Z working area |
150mm |
|
Spindle power |
2.2KW water cooled |
|
Control system |
NC-Studio/ DSP |
|
Transmission |
X Y rack transmission, Z-axis screw |
|
Max carving speed |
10m/min |
|
Resolution |
0.005mm |
|
Repeatability |
0.025mm |
|
Max feeding height |
150mm |
|
Command |
G code*.u00*.mmg*.plt |
|
Surrounding for software |
Windows 2000/XP |
|
Power (not including spindle) |
300W |
|
work mode |
Stepper motor |
|
Working table |
T-slot with water sink |
|
Spindle rotating speed |
0-24000rpm/min |
|
Work voltage |
AC220V/380V 50-60Hz |
