Small Simple 120mm Laser Tube Cutting Machine Round Square 1500W High-Precision Laser Cutting Machine for Metal

support OEM Order,laser power 1.5kw-6kw,chuck diameter 120-650mm,length 6m/9m/12m
Contact

Product Details

Product Description
The model is extremely cost-effective, It is capable to cut metal tubes up to 6 meters and the shortest tailing waste is only 40mm, which is a great saving of cost. It is an ideal choice for pipe processing enterprises. From configuration selection to assembly process, from post-training to after-sales service, the machine truly creates a laser cutting machine that customers can afford!
Specification
Model
Fiber laser cutting pipe machine
Tube length
6000mm
Maximum diameter
15-650mm
Fiber power
1500w/2000w/3000w/6000w
Laser length
1064nm
Beam quality
<0.373mrad
Cutting accuracy
± 0.05mm
Repeated positioning accuracy
± 0.03mm
Maximum operation speed
40 meters/minute
The cutting speed
Depends on the material
Auxiliary gas
IAir/N2/O2
Position Type
red dot
Working Voltage
380V/50Hz
